It can meet the filling requirements with different sealing caps such as crown cap, pop can cap, aluminum cap, twist cap (iron cap), screw cap(plastic cap),which is applied to water, carbonated soft drinks and juice.
The entire line includes the following optional equipment: depalletizer, rinser, bottle washer, rinsing/filling/capping 3-in-1 monoblock, filling-capping 2-in-1 monoblock, bottle warmer, inkjet printer, labeling machine, packaging machine and etc..
Full Automatic PET Bottle Green Tea Bottling Machine
Model
RCGN32-32-10
Number of Working Positions
Rinser 32, Filler 32, Capper 10
Rated Capacity
12,000 BPH(500ml)
Filling Method
Hot Filling
Applicable Bottle
PET Bottle, Diameter 60-97mm, Height 150-320mm
Applicable Cap
Normal Standard Cap
Air Supply Pressure
0.6 MPa
Air Consumption
0.8M3/min
Rinsing Water Pressure
0.2~0.25 MPa
Rinsing Water Consumption
About 1.5-2T/H
Filling Temperature
85-90ºC
Rated Voltage
380V
Installed Power
4.18 KW
Dimensions
About 4140mm×2560mm×2850mm (L×W×H)
Machine Weight
About 7500Kg
Product: Fruit juice/Tea/energy drinks etc Volumn: 330-4000ml Production capacity: 3000-36000 bottles/hour Diameter of bottle neck: 28mm 38mm Filling type: Gravity filling Filling temperature: 85-90
Jiangsu MESURE machinery Co., Ltd is a professional company engaging in designing, manufacturing, installation, commissioning and training of drinking water, juice, carbonated soft drink, dairy drink and alcohol industry.
